Widely used for maintenance operations and for assembly when specific torque levels are required or adjustments needed.

Heat-treated chrome alloy ratchet gear with reinforced pawl blocks for maximum strength.
Handle has permanently etched newton metre scale and laser mark foot pound scale on the reverse side. The pull down locking ring above handle grip securely holds set torque value. Permanently etched newton metre scale and laser mark foot pound scale on the reverse side.
Signals torque in both left & right directions and is accurate to ± 4% clockwise direction and ± 6% counterclockwise direction, from 20% of full scale to full scale reading.

Supplied with calibration certificate at time of manufacture. Supplied in a blow mold case

  • Size: 3/8" Drive
  • Increments: 0.5Nm  (0.37Ft/lb)
  • Length: 440mm
  • Range: 20 to 110Nm (14.7 to 81.3Ft/lb)



Barcode # 9322159642063
